LS22 Mercedes-Benz Magirus DLK v1.0.0.0
LS22 Mercedes-Benz Magirus DLK v1.0.0.0
Mercedes-Benz Magirus M32L-AS articulated turntable ladder
Turntable ladder M32L-AS
The Magirus M32L-AS articulated turntable ladder with a four-section ladder set and single extension improves the weight distribution and increases the payload for more loading.
Chassis: 16 t class chassis
e.g. IVECO MAGIRUS EuroCargo 160 E 30 4×2
or comparable chassis from other manufacturers
Engine [hp]: 220 KW / 299 hp
Wheelbase: 4,815 mm
Cab + seats: All-steel 1 + 2
Total weight: 15,000 /16,000 kg
Rescue height: 30.5 m
Operating height: 32 m
Rescue cage RC300: 3 persons
Advantages & special features of the M32L-AS
The Magirus M32L-AS articulated turntable ladder with innovative, patent-pending Magirus single extension system enables the top section of the ladder to be extended first – followed by all other ladder sections. The improved weight distribution between the axles, the relief of the rear axle and a fundamental reduction of the overall weight enable more payload for more fire-fighting equipment. In addition, the Magirus M32L-AS has more outreach by reducing the weight at the top of the ladder at 32 m operating height and 4.7 m articulated arm without telescope in the articulated arm. Other special features are the increased water capacity of up to 2,500 l thanks to the new water feed-through and faster set-up times. All the advantages of Magirus turntable ladder technology also apply to this new type of turntable ladder.
All rights reserved by Austria Modding
